HANWHA SM320 321 411 421 screw SPLINE ALIGNER J7055545B

HANWHA SM320 321 411 421 screw SPLINE ALIGNER J7055545B

Specifications:

31 FC18-902756 SOCKET HEAD CAP SCREW M5*12 (NI/ZN) 2

32 FC18-902745 SOCKET HEAD CAP SCREW M4*15 (NI/ZN) 4

33 FC18-902745 SOCKET HEAD CAP SCREW M4*15 (NI/ZN) 8

A-2 J9053343A BACK UP TABLE ASSY(LARGE)[J9053343A] 1

A-3 J90531035A BACK_UP_TABLE_ASSY-EXL J90531035A 1

1 J70590095C CAMERA BOARD COVER 2

2 J91741051A SSA_VIS_FIX_IF_BOARD LEDIF02 2

3 FC15-001295A LIGHT_COVER 1

4 FC09-002220A BRACKET-LIGHT 1

5 AM03-026489B ASSY,BOARD-STAGE SIDE LIGHT BOARD 1

6 AM03-026488B ASSY,BOARD-STAGE OUTER LIGHT 4

7 FC09-002219A BRACKET-LIGHT_G_2 1

8 FC15-001491A COVER-LIGHT COVER 1

9 FC29-900611 HEX SUPPORT 8

10 FC15-001294A COVER-PROFILE 1

11 FC09-002218A BRACKET-GLASS_STOP 2

12 EP12-000044A GLASS,OPTICS-GLASS 1

13 PT02-000048A DIFFUSER,OPTIC-DIFFUSER 1

14 FC29-900610 HEX SUPPORT 4

15 J90600073C LED BOARD ASSY STAGE INNER LIGHT 1

16 FC09-002222A BRACKET-PCB_BASE_2 1

17 FC09-002221A BRACKET-PCB_BASE_1 1

18 FC05-000225A BASE 1

19 FC15-001293A COVER-PROFILE_1 1

20 J9059118A LENS ASSY 1

21 PT02-900001 CCD CAMERA 1

22 FC15-001290A COVER-COVER_1 1

23 FC15-001292A COVER-COVER_COMP 1

24 J7066008D LINK_SHAFT_1 1

25 FC15-001291A COVER_2 1

26 FC18-902837 SEMUS NABE SCREW 8

27 AM03-015218B ASSY,OPTICS-SM482_STAGE_MEGA_35_ASSY 1 AM03-015218A / AM03-007707B F35 MEGA Type / #1~2782

AM03-031495A ASSY,OPTICS-SM482_STAGE_MEGA_35_ASSY 1 F35 HEXA Type / #2783~

AM03-015217B ASSY,OPTICS-SM482_STAGE_MEGA_45_ASSY 1 AM03-015217A / AM03-007727B F45 MEGA Type / #1~2782

AM03-031493A ASSY,OPTICS-SM482_STAGE_MEGA_45_ASSY 1 F45 HEXA Type / #2783~

28 FC29-900611 HEX SUPPORT 8
